Designed Especially For Framing Nailers.
Oil lubricated for cooler operation and reduced noise
High output cast iron pump delivers maximum performance and operational life
Big BoreTM cylinder and piston feature high output at lower RPM with reduced heat buildup, less noise and longer operational life
Low amperage draw reduces incidents of tripped breakers and voltage drops that cause premature motor failure
Easy view oil gauge and large pressure gauges for quick identification
Air pressure regulator enables easy adjustment of line pressure
Features 2 quick connect air hose fittings
Finned discharge tube promotes safe and efficient cooling
Stores 50′ of 3/8″ air hose with handle folded or upright
INCLUDES: 1/4” Quick Coupler, (10TT-8), Compressor Oil (0.25L) (181122-A)
SPECIFICATIONS
Motor 3.0 hp
Pump Oil-Lubricated
Tank 5.2 gal (19.7L)
Performance (90 PSI) 6.5 CFM
Noise level 90 dB(A)
AMPS (120V) 13.8 A
Dimensions (L x W x H, with Handle Folded) 30-5/16″ x 20 x 21-13/16″ (770 mm x 510 mm x 553 mm)
Maximum Pressure 140 PSI
Net Weight 88.0 lbs (39.9 kg)
